Bridges

King Coal Highway


White House Bridge


Mt Olive Bridge


Campbell Co. Bridge


Hillsdale Drive

Hillsdale Drive Extension Charlottesville, VA This $15 million project alleviated traffic from the Route 29 corridor north of Charlottesville by completing a connection between Rio Road and Hydraulic Road, east of Route 29. Hillsdale Drive was extended by 1 mile and included a new traffic signal, a roundabout, 3600 feet of shared-use path, 5800 feet of sidewalk, and a 160’ bridge over a stream. The project started in June of 2016 and opened December 22, 2017, and included almost 10,000 tons of asphalt and over 43,000 tons of stone. Similar Projects Colonial Ave Sunchase at Longwood 12345
